SYSTEM DESCRIPTION

PRINCIPLE OF OPERATION

The solar coil and water heater's volume are adjusted to maximum 6 m
2
area of 0,75 m .

SYSTEM DIAGRAM

Compact Sol has been specially developed to work with NIBE solar control, SCU 10. The solar panel's charge
automation must be limited to a max temperature of 80 °C. This is to prevent temperatures higher than 85 °C in
the water heater.
-CP1
-EP30-BT54
Note: This is an outline diagram. Actual installations must be planned according to applicable regulations.
Components
EP30 Solar control SCU 10
AA25 Control unit
BT53 Temperature sensor, solar panel
BT54 Temperature sensor solar
GP30 Pump station SPS 10/SPS 20
FL4 Safety valve, solar
GP4 Circulation pump, solar
QM43 Shut-off valve
NIBE Compact Sol | GB
-EP30-BT53
-EP8
-EP30
-GP30
-AA25
-RM4
T
-RM3
-GP4
-QM45
2
solar panel area. The solar coil has an
-CM5
T P
-FL4
-QM44
-QM43
QM44 Shut-off valve
QM45 Shut-off valve
RM3 Non-return valve
RM4 Non-return valve
Miscellaneous
CP1 Compact Sol
CM5 Expansion vessel, solar circuit
EP8 Solar panel
