Contents
1. General
2. Safety
3. Description
4. Assembly
5. Commissioning
6. Maintenance
7. Break‐down and elimination of the defects
1. General
We presume that you are experienced in the field of irrigation. Therefore we have kept this instruction as
briefly as possible, and have included such information only, which you must have for the use of this product.
A guarantee can be accepted only, if the sprinkler has been operated in accordance with these instructions,
and if the defect occurs within the guarantee period.
1.1. Application
The sprinkler is used for the uniform distribution of the water. The water should be pre‐cleaned, and
free of coarse and fibrous impurities.
Max. water temperature will be 50 degree C.
Max. ambient temperature will be 75 degree C.
2. Safety
These operation and safety instructions include basic remarks and hints for the assembly, installation,
operation, maintenance, inspection and repair. For this reason these instructions must be read by the fitter,
as well as by the customers authorised staff, prior to the installation and commissioning.
Apart from the general safety instructions of this paragraph the special safety instructions include in other
paragraphs of these operating instructions have to be observed also.
2.1. Symbols of hints given in these operating instructions
The non‐observance of the safety instructions mentioned in these operating instructions can
endanger persons, are
marked with the general danger symbol
Safety instructions which can endanger the sprinkler and its function, if not observed, are specially
marked and the word
2.2. Dangers if the safety instructions are not observed
Non‐observance of the safety instructions can endanger persons as well as the environment and the
sprinkler. Non‐observance of the safety instructions can result in a loss of all claims for indemnity.
3. Description
Recommended operating pressure
Permissible operating pressure
For further data please refer to the separate data leaflet.
TDP002d‐e‐f.doc
Perrot REGNERBAU CALW GmbH Industriestraße 19‐29 / D‐75382 Althengstett / Germany
Telefon : 0049‐7051‐162‐0 / Fax : 0049‐7051‐162–133
E‐mail: p errot@perrot.de / E‐mail Konstruktion : technik@perrot.de
5 to 7 bar
4 to 10 bar
The pressure at the sprinkler must not exceed 10 bars.
Rev. 26.11.2015
especially.
has been inserted.
Seite‐Page‐Page 8 / 20
