Installing the cranks

Install your chainwheels to the axle crank.
CAUTION !
Danger of damage to the chainwheel mounting.
NOTE !
It is essential to read and observe the safety and
working instructions given in the manual of the
manufacturer of the chainwheels and chain-
wheel securing bolts!
Slightly grease the bearing seat(1) of the axle.
1
(Fig. 5)
5
Introduce the axle crank into the bottom bracket
up to the limit stop.
(Fig. 6)
6
The number of chainwheel teeth must
NEVER be inferior to the minimum number
required – see D
IMENSIONS
ASSEMBLY
, page 51!
55
