Annex

Standard:
Frequency range:
Transmission per-
formance:
SMA socket:
Voice transmission:
Fax mode:
Modem mode:
Dialling mode:
Connectable telephones:
CLIP:
Operating temperature:
Relative humidity:
Permissible
storage temperature:
Display unit:
Dimensions:
Weight:
Mounting location:
Power supply:
Delivery package:

Product approval/CE mark

This device is approved for the connection and use within the analogue
public telephone networks in all EC countries - according to the European
Requirements. Due to technical deviations in individual countries, we
cannot grant an unlimited guarantee for the successful operation at all
types of telephone accesses.
Tiptel hereby declares that the device complies with all fundamental
requirements of the European directive 1999/5/EC. This conformity is
confirmed by the CE sign on the device.
Further details on the declaration of conformity can be found under the
following internet address: http://www.tiptel.org
Cleaning
Simply wipe the device with a slightly damp cloth or with an antistatic
cloth; do not use a dry cloth. Do not use cleaning or scouring agents.

Technical data

DECT (Digital Enhanced Cordless
Telecommunications), GAP-compatible
1880 MHz to 1900 MHz
10 mW on average
For connecting an external aerial via
coaxial cable (DECT Box 5000 only)
32 kbit/s ADPCM
Group 3, V.29, 9600 bit/s maximum
9600 bit/s maximum
DTMF
Up to three standard telephones can be
connected in parallel
Transmission via FSK1; protocol
conforms to ETSI standard
+10°C to +40°C
20% to 75%
-10°C to +60°C
LED
120 x 100 x 38 mm (W x H x D)
140 g
Wall mounting in interior rooms
10 V AC (0.12 A zero signal current, 0.4 A
maximum); alternatively, 12 V DC +/- 15%
= 10.2-13.8 V (0.12 A zero signal current,
0.4 A maximum)
230 V AC, 50 Hz power supply unit,
optional adapter
17
