08.2008
Designation
Order number 6SE70...
Rated voltage
Input
Output
Rated frequency
Input
Output
Rated current
Input
Output
DC link voltage
Rated output [kVA]
Aux. power supply
Pulse frequency [kHz]
Derating curve
Load class II acc. to EN60146-1-1:
Base load current
Overload current
Cycle time
Overload duration
Losses, cooling, power factor
Power factor
Line cosϕ1N
Converter cosϕU
Efficiency η
Pulse frequency 5 kHz
Dissipated losses [kW]
Pulse frequency 5 kHz
Cooling air required [m³/s]
Sound pressure level, dimensions, weights
Sound pressure level [dB(A)]
Type of construction
Width
Height [mm]
Depth
Weight
Siemens AG 6SE7087-6JK50
SIMOVERT MASTERDRIVES
31-0EE 0 31-2EF 0
[V]
3 AC 380 to 480 (-15 % / +10 %)
3 AC 0 ... rated input voltage x 0.86
[Hz]
[A]
101 136
92 124
[V]
61...76 82...103
[V] DC 24 (20 -30) (3.0 A without options; more with options)
5.0 – 10.0 5.0 – 10.0
0.91 x rated output current
> 0.98 > 0.98
< 0.92 ind. < 0.92 ind.
0.97 0.97
1.38 1.83
0.10 0.14
69 69
E F
270 360
1050 1050
350 350
[kg] 55 65
*) With Z = F02; 2.5 kHz pulse frequency
= 5 corresponds to MASTERDRIVES Motion Control
= 7 corresponds to MASTERDRIVES Motion Control Performance 2
Operating Instructions
Value
31-8EF 0 32-1EG 0
50/60 ± 6 %
0 ... 400
171 192
155 175
186 *) 210 *)
510 ... 650
102...128 115...145
5.0 – 9.0 5.0 – 7.5
5.0 – 6.0 *)
1.6 x rated output current
300 s
30 s
> 0.98 > 0.98
< 0.92 ind. < 0.92 ind.
0.97 0.98
2.43 2.77
0.14 0.31
69 80
F
360 508
1050 1450
350 350
65 155
Technical Data
32-6EG 0
238
218
260 *)
143...181
5.0 – 7.5
> 0.98
< 0.92 ind.
0.98
3.45
0.31
80
G G
508
1450
460
155
11-5
