4 Carefully check the whole area to be mown. Remove all foreign objects, such as stones, sticks, wires, bones, etc. Use the mower only in
daylight or if the working area is well illuminated.
5 Do not start the engine if anyone is standing in front of the cutter bar – the cutter and wheel drives must not be engaged.
6 Always mow across a slope. Never mow up or down a slope or on slopes with an inclination higher than 10°.
7 During operations you need to use ear protectors, sturdy footwear and long trousers should be worn. Be very careful, when working, the
blade is potentially hazardous for hands and feet. Always walk and never run while operating the machine.
8 During the machine transport and all the maintenance, cleaning, equipment change operations, the engine must be switched off. The blade
guard must be mounted on the cutter bar if the mower is transported or lifted. Before leaving the machine, please switch the engine off.
9 Do not start the machine in closed rooms/areas to avoid dangerous carbon monoxide fumes.
10 WARNING !! The petrol/gasoline is highly inflammable. Every operation ( fill-in or emptying of the fuel tank ) must be done in open air and
keeping the engine switched off, don't smoke and be careful of the petrol/gasoline leakages from the tank. In case of leak, don't try to switch
the engine on but move the machine away from the area in order to avoid ignition source until the gasoline vapours fade away. Re-place the
tank caps and the gasoline can.
11 Keep attention to the exhaust pipe. The parts near the pipe can reach 80°C. Keep the exhaust and engine free of leaves, grass and spilt oil.
12 The cutter drive must be disengaged when the mower is not on grassland.
13 If the machine is incorrectly used, and/or the repairs are performed by non-authorized technical staff, and/or non original equipments
are fitted, and/or non original parts are used the warranty will decline and the manufacturer will not be liable for any damages to persons or
properties.

TRANSPORT

n
A forklift truck should be used to move the machine. The forks should be opened as far as possible and inserted into the pallet.
The weight of the machine is given on the Manufacturer's data plate together with the other technical information.
ASSEMBLY SCYTHE- MOWER
n
For assembly to be completed, the step/ by/ step procedure is a follows:
n ASSEMBLY HANDLEBARS SUPPORT AND HANDLEBARS (Fig. 17)
screws (2) and respective washers (3 outside diam. 17) and (4 outside diam. 24): WARNING: washers having larger diameter must be fitted to match
slots (10). Assemble the antivibrant band (9) under the support (1) in correspondence to the holes, then fix the mowing bar (5) by the screws (6)
rubber washer (7) and elastic washer (8).
n ASSEMBLY OF THE THROTTLE CABLE ON ENGINE B&S (Fig. 2-3)
the stop position. Using the corresponding key, take off the screw (2) and protective covering clamp (4).
After that, put the throttle hand-lever (part. 1 fig.15), fixed to the handlebar , on the stop position and the "S" of the wire into the slot (3) which is marked
with the arrow on the engine leverage (1). Position the protective covering on the base of the clamp and tighten it using the screw (2).
Unless otherwise agreed, the scythe – mower is delivered disassembled and placed in a packing case.
Assemble the support (1) on the machine by the 4
Move the throttle lever (1), positioned on the engine, on
