7 Parameter settings
Parameters Setting range
Min / Max
Interlink func-
tion
Off
On
Program-
mable output
Inactive
(230V)
Heating circuit re-
quest
Circulation request Circulation pump – The output is activated either after the time program of
Direct heating cir-
cuit request
Func. burner Resistance values Selection of the functionality of the EXT switching contact (J8) (see
blocking con-
Burner blocking
tact
contact
Operating Instructions
36
Description
Configuration for systems that are operated with 2 different feed target
temperatures (see Chap. 4.4.4).
One possible application is, for example, the additional integration of an
HP convector in a surface heating and cooling system.
Prerequisite: 2 room thermostats are connected to Daikin Altherma EHS(X/
H) plug connection J16.
Deactivated
Evaluation of the heating and cooling switching contacts at plug connec-
tion J16 on the PCB of RoCon BM2C.
Activation of cooling mode only by switching the operating mode to "Cool-
ing" (see Chap. 4.1).
Setting of the [Room thermostat] parameter is no longer evaluated.
▪ Open switching contacts: Only frost protection active
▪ "Heating" and "Automatic 1" / "Automatic 2" operating mode active dur-
ing the switching cycles in day mode.
▪ Closed heating switching contact = IL1:
▪ It is regulated to the normal feed target temperature in accordance
with the parameter settings in [→ Main menu → Configuration
→ Heating].
▪ Closed cooling switching contact = IL2:
▪ The system is regulated to the increased feed target temperature
(normal feed target temperature + value of the [Interlink temperature
rise] parameter. Priority if both switching contacts are closed!
▪ "Cooling" operating mode active.
▪ Closed heating switching contact = IL1:
▪ It is regulated to the normal feed target temperature in accordance
with the parameter settings in [→ Main menu → Configuration
→ Heating].
▪ Closed cooling switching contact = IL2:
The system is regulated to the reduced feed target temperature (normal
feed target temperature value of the [Interlink temperature reduction] para-
meter. Priority if both switching contacts are closed
Configuration of the multi-function output (230 V, J14 connection):
The output has no function.
Header pump – The output becomes active as soon as a system heating
circuit reports a heat requirement to the heat generator.
the circulation pump or after the time program of the domestic hot water
preparation, depending on the parametrisation (see
Feeder pump – The output becomes active as soon as a heat requirement
is pending for the direct heating circuit of the heat generator.
4.1)
Factory
setting
Chap. 4.3).
Chap.
Daikin Controller RoCon+ HP
008.1444299_01 – 09/2018 – EN
Incre- Access
ment
BE HF
- N E
- N E
- N E
