PART NAMES

FRONT VIEW

REAR VIEW

NOTE: Actual unit might vary slightly from above illustration.
1
1 Air Outlet
2
2 Vertical louvers
3
3 Horizontal louvers
4
4 POWER Button
5
5 Signal receiver for remote
control
6
6 AIR CON Lamp (green)
7
7 TIMER Lamp (orange)
8
8 MAXIMUM Lamp (red)
9
9 ION GENERATOR Lamp
10
(blue)
10
10 Air inlet
10
11
11 Exhaust air outlet
12
12 Window adapter
13 Exhaust hose
13
14 Remote control hook
14
15 Air filter
15
16 Grille
17 Air inlet
18 Drainpipe and stopcock
16
19 Power plug
17
20 Casters(4)
18
19
20
