Technical specifications
This chapter contains the technical data of the TP1000F Mobile which differ from the technical data of the KTP900F Mobile.
You can find all other specifications in the "Mobile Panels 2nd Generation" operating instructions.
Mechanical system
Weight without packaging
Display
Type
Display diagonal
Resolution
Number of colors
Brightness control
Backlighting
Half Brightness Life Time (MTBF
Pixel error class in accordance with EN ISO 9241-307
Operating hours after which the maximum brightness is reduced by half compared to the original value. MTBF is
1
increased by using the integrated dimming function, for example, time-controlled via screen saver or centrally via
PROFIenergy.
Input device
Type
Function keys
Labeling strips

Technical Support

You can find technical support for your device by entering the MLFB under:
● Technical Support (https://support.industry.siemens.com)
Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
TP1000F Mobile
A5E39831604-AA, 12/2017
10
)
1
TP1000F Mobile
Approx. 1650 g
TP1000F Mobile
LCD TFT
10''
1280 × 800 pixels, wide screen
16.2 million
By software
LED
≥ 70,000 h with a brightness of 50%
II
TP1000F Mobile
Touch screen, analog resistive
No
No
TP1000F Mobile
