Mechanical system
Weight without packaging
Weight with packaging
Height of fall
Input device
Type
surface
Function keys
Labeling strips
Connecting cable
Bending radius, minimum
Rated condition, temperature
Connection boxes
Enabled
Rated condition, temperature
Climatic ambient conditions

Operating Conditions

The following information applies to the HMI device, the connection boxes and connecting cables. The devices are designed
for operation in a location protected from the effects of the weather.
Contrary to what is stated in the operating instructions of the basic unit: The connection boxes from section "Connection
boxes (Page 10)" and connecting cables from section "Connecting Cable (Page 10)" are released for the extended operating
temperature range "Arctic" in combination with the HMI device.
Type of condition
Temperature, HMI device
Temperature, connection boxes -28 °C to 55 °C
Atmospheric pressure
Relative humidity
HMI device, connection box, Advanced: No condensation inside the enclosure.
1
Connection box compact: No condensation on the rear
Note: Condensation endangers the interior of the device
After transporting the HMI device at low temperatures or if the HMI device has been exposed to temperature fluctuations,
moisture can condense on the HMI device or inside the device (condensation). The device can be damaged with
consequences for the machine or plant.
Let the HMI device warm up to room temperature before switching it on.
•
Do not expose the HMI device to direct radiation from a heater to warm it up.
•
In case of condensation, dry the HMI device completely or switch it on only after a waiting period of about 4 hours.
•

Technical Support

You can find technical support for your device by entering the MLFB under:
● Technical support (https://support.industry.siemens.com/cs/ww/en/)
KTP700F Mobile Arctic
A5E49199858-AA, 02/2020
14
≥ 4-times the outside diameter of the line
See section "Climatic ambient conditions (Page 14)"
Connection box compact
Connection Box, Advanced
See section "Climatic ambient conditions (Page 14)"
Permitted range
-28 °C to 45 °C
1140 hPa to 795 hPa
10% to 90%
1
Comment
Extended operating temperature range "Arctic"
corresponds to an elevation of -1000 m to 2000 m
No condensation
1
KTP700F Mobile Arctic
1435 g
1640 g
1.2 m
KTP700F Mobile Arctic
Touch screen, analog resistive
GFG (glass film glass) touch
8
No
