SECTIoN 2
WarNINg

2.1 general

As shipped, the ESP-101 is fully assembled and ready to cut after being connected to input power, a source of
compressed air, and a PT-37 torch. The ESP-101 system uses the heavy-duty PT-37 (Mechanized Plasma) torch to
deliver cutting power for cutting materials up to 1-1/4 inch (32 mm) thick. Refer to the following pages for de-
scriptions of the ESP-101 packages available as well as performance specifications.

2.2 Scope

The purpose of this manual is to provide the operator with all the information required to install and operate the
ESP-101 Plasma Arc Cutting System. Technical reference material is also provided to assist in troubleshooting the
cutting system.
uSE ThE ESaB PT-37 PlaSMarC TorCh WITh MEChaNIZED CoN-
SolES. uSE of TorChES NoT DESIgNED for uSE WITh ThIS CoN-
SolE CoulD CrEaTE aN ElECTrIC ShoCK haZarD.
11
DESCrIPTIoN
