Important notes

If assembled incorrectly, the sauna
heater will present a fire hazard. Please read
this installation guide thoroughly. It is es-
pecially important to observe the minimal
clearances and follow the present instruc-
tions:
• This device has not been designed for being
used by persons (including children) that
are physically or mentally handicapped or
have sensory disabilities. Moreover, it is not
allowed to use this device without sufficient
experience and/or knowledge, unless these
persons will be supervised by persons re-
sponsible for their security or in case they
have been instructed how to use this device.
• Children are to be supervised in order to
make sure that they do not play with this de-
vice.
• The installation and connection of the
sauna heater, control unit and other
electrical equipment must be accomplished
only by an expert. In this regard it is especial-
ly important to meet the required safety pre-
cautions in accordance with VDE 0100 v. §49
DA/6 and VDE 0100 part 703/2006-2.
• The sauna heating and control units may be
installed only in sauna cabins made of suit-
able, low resin and untreated material (e.g.
Nordic spruce or pine)
• Only a sauna heater with the appropriate
heating capacity may be installed in the sau-
na cabin.
• There should always be a provision for air in-
take and exhaust vents in every sauna cabin.
The air intake vents must be installed behind
the sauna heater, ca. 5 to 10 cm above the
floor. Please use the minimum dimensions of
the air intake and exhaust vents.
• The exhaust vent must be placed opposite
to the sauna heater diagonally in the sauna
wall (lower area). The air intake and exhaust
vents must not be closed. Please observe the
information provided by your sauna cabin
20
supplier.
• For the adjustment and control of the sauna
heating unit, one of the control units men-
tioned later must be used. This control unit
must be attached to a suitable location on
the outer wall of the cabin, the associated
sensor housings in the interior of the sau-
na cabin in accordance with the installation
guide which accompanies the control units.
• Caution: Covering and improperly
filled stone receptacles present a fire
hazard.
• Make certain that no objects have
been placed on the sauna heating
unit before each start-up.
Caution: High temperatures on the
•
heater during operation may cause
burns on contact.
• The sauna heater is not intended for installa-
tion or placement in a niche under the bench
or under a roof slope.
• Do not start up operation of the sauna heater
with air intake vents closed.
• The cabin lighting with corresponding
mounting must be watersplash-proof type
and able to withstand a surrounding temper-
ature of 140° C. Therefore only a heat-resist-
ant sauna lamp with max. 40 W bulb may be
installed in the sauna cabin.
• The sauna system (sauna heater, con-
trol unit and lighting etc.) may be con-
nected to the power source only by a locally
certified electrician. All connecting lines laid
on the inside of the cabin must be made of
silicone-coated cablle and should withstand
a surrounding temperature of at least 170°C.
If single-core cables are used as connecting
lines, they must be protected by flexible
metal tubing. The minimum diameter of the
connecting line and the suitable cabin size in
proportion to the power supply capacity are
listed in the table.
• During the installation of the sauna heater
make certain that the vertical clearance be-
tween the upper edge of the sauna heating
unit and the sauna ceiling is observed . The
