Cutting variants
Mitre/bevel cut:
This cut is executed in the same way as a mitre cut and bevel cut. The board can also be mitred when exe-
cuting the bevel cut.
Rebate and section cut-outs:
Transfer the relevant dimensions to the foam board and position the board on the
bearing rail (no. 8). Extract the cutting bow (no. 1) to the desired rebate measure-
ment - you can read the relevant dimension on the scale for section cut-outs (no.
14) on the lower frame of the cutting bow. Undo the fixing screw for the upper and
lower depth limiter (no. 15), slide the limiter as far as the stopper and re-secure
the screw. Guide the board to the left until the wire has reached the end of the
marking and then pull the wire from the board.
When making a section cut-out repeat the previously described process, but start
by guiding the wire through the board at the desired point up to the stopper. When
this area has been reached the board is offset to the left as far as the marking and
then the cutting bow is removed from the board again.
