English
Index / page
1. GROUP I (about 9 to 18 kg Y)
1.1. Using HEYNER® CapsulaProtect 3D HEYNER® CapsulaProtect 3D as a child car seat
1.2. Adjusting HEYNER® CapsulaProtect 3D HEYNER® CapsulaProtect 3D to your child's size
1.3. Installing HEYNER® CapsulaProtect 3D HEYNER® CapsulaProtect 3D into your car
1.4. Travelling with the HEYNER® CapsulaProtect 3D HEYNER® CapsulaProtect 3D
2. Care instructions
3. Important notices
4. Some final hints
A1 – Head cushion N – Backrest
A2 – Reduction cushion O – Fabric Cover
B – Shoulder pads P – Shock minimizer
BL – Base holes PG – Positioning handle
BT – Base part R – Belt anchorage
C – Buckle latches S – Installation sticker
D – Buckle SB – Safety bolt
E – Seat cover SG – Connector belts
F – Adjuster cover SR – Safety lock
G – Belt system ST – Seat part
G1 – Belt slots U – Diagonal belt of the
G2 – Harness belts three-point-vehicle-belt
G3 – Waist belt V – Buckle latch of the
three-point-vehicle-belt
G4 – Buckle belt
G5 – Central harness belt VH – Conntecting hook
GK W
– Belt clip – Lap belt of the
GN
– Belt lugs three-point-vehicle-belt
I X – Belt buckle of the three-
– Belt adjuster
point-vehicle-belt
L – Installation manual storage
www.heyner-germany.de
11
1. GROUP I (about 9 to 18 kg Y) 1. GROUP I (about 9 to 18 kg Y)
1.1. Using HEYNER® CapsulaProtect 3D as a child car seat 1.1. Using HEYNER® CapsulaProtect 3D as a child car seat
S. 12
S. 12
You have purchased HEYNER® CapsulaProtect 3D HEYNER® CapsulaProtect 3D car seat
S. 12
S. 14
for your child. We thank you for your trust. Please note, that
S. 17
the optimum safety characteristics can only be achieved, if
S. 18
the seat is used properly according to instructions. There-
S. 19
fore we ask you to ensure the correct installation of the seat
S. 20
in your vehicle by reading the operating instructions
carefully. Please keep instructions always with the seat for
further information. Only to be assembled and mounted by
adults!
1.2. Adjusting HEYNER® CapsulaProtect 3D to your child's 1.2. Adjusting HEYNER® CapsulaProtect 3D to your child's
size size
1.2.1. Preparation 1.2.1. Preparation
fig.1a-c fig.1a-c
• HEYNER® CapsulaProtect 3D HEYNER® CapsulaProtect 3D carries a head cushion (A1)
and a reduction cushion (A2), to assure special protection
of small children starting from about 9kg - 18kg.
• We recommend removing the reduction cushion only,
when the child has become too big for it, latest when the
child weight is over 18 kg.
• The HEYNER® CapsulaProtect 3D HEYNER® CapsulaProtect 3D seat is equipped with its
own belt system (G) - the harness belts - which needs to
be adjusted to your child's size as follows:
• Place HEYNER® CapsulaProtect 3D HEYNER® CapsulaProtect 3D on a normal chair and
set your child in it. To ensure optimum positioning of the
www.heyner-germany.de
English
1.2.2. Height and length adjus
GB
HEYNER® CapsulaProtect
fig.2
fig.2a
