4.6 Explana on of display and keypad
4.6.1 Display in measuring mode
Display
8
7
1 Bar graph
The bar graph displays from 0 ... 100 % of the measuring range of the currently connected
pressure sensor LPC-2
informa on about the current load on the connected
2 Ba ery level display
The ba ery level display indicates from 0 ... 100 % of the charge level. It is ' illed' to
x % based on the current ba ery charge and it gives informa on about the current
charge level of the ba ery.
3 TARE func on (if ac vated)
4 Current measured pressure value
5 Current unit and type of pressure
•
Gauge pressure: without iden ica on;
•
Absolute pressure: iden ied by an addi onal "ABS"
6 Temperature unit (
7 Current measured temperature via the external temperature sensor (model
LR-Cal LPC 200-T)
8 Display of the pressure
Tel. +49 (0) 7121-90920-0 • Fax +49 (0) 7121-90920-99 • DT-Info@Leitenberger.de •
Cal Cal
LPC 200 + LR-
1
. It is ' illed' to x % based on the current pressure value and it gives f
model LR-Cal LPC 200-T
measuring rate
DRUCK & TEMPERATUR Leitenberger GmbH • Bahnhofstr. 33 • D-72138 Kirchentellinsfurt • GERMANY
LPC 200-T
2
3
4
5
6
LPC-2 reference
)
