Setup Procedure

1. Determine the installation location
CAUTION: DO NOT ATTEMPT TO INSTALL THE LCD
MONITOR BY YOURSELF
Installing your LCD display must be done by a qualified technician.
Contact your dealer for more information.
CAUTION: MOVING OR INSTALLING THE LCD MONITOR
MUST BE DONE BY TWO OR MORE PEOPLE.
Failure to follow this caution may result in injury if the LCD monitor
falls.
IMPORTANT: Lay the protective sheet, which was wrapped around
the LCD monitor when it was packaged, beneath the
LCD monitor so as not to scratch the panel.
2. Install the remote control batteries
The remote control is powered by 1.5V AA batteries. To install or
replace batteries:
1. Press and slide to open the cover.
2. Align the batteries according to the (+) and (–) indications
inside the case.
3. Replace the cover.
➀ Remove the cover ➁ Insert the batteries ➂ Replace the cover
CAUTION: Incorrect use of batteries can result in leaks or
bursting.
Be careful especially about the following points.
• Place "AA" size batteries matching the + and - signs on each
battery to the + and - signs of the battery compartment.
• Don't mix battery types.
• Don't combine new batteries with used ones.
It causes shorter battery life or leakage of batteries.
How to Mount and Attach Options to the LCD Monitor
You can attach mounting accessories to the LCD monitor in one of
the following two ways:
In the upright position
01_English 5
• Remove dead batteries immediately to prevent battery liquid
from leaking into the battery compartment.
Don't touch leaked liquid, it causes damages to your skin.
NOTE: If you do not intend to use the Remote Control for a long
period, remove the batteries.
3. Connect external equipment
(See pages 7~12)
• To protect the connected equipment, turn off the main power
before making connections.
• Refer to your equipment user manual.
4. Connect the supplied power cord
• The power outlet socket should be installed as near to the
equipment as possible, and should be easily accessible.
• Fully insert the prongs into the power outlet socket.
Loose connection may cause noise.
5. Switch on the power of all attached
external equipment
When connected with a computer, switch on the power of the
computer first.
6. Adjust the sound
Make adjustments when adjustment of the volume is required.
7. Adjust the screen (See pages 14~22)
Make adjustments when adjustment of the screen display position
or distortion is required.
8. Adjust the image (See pages 14~22)
Make adjustments when picture adjustment such as the brightness
or contrast is required.
9. In case of portrait position
• Remove the stand.
• Left side of monitor must become upper side (seen from front).
Lay the screen face down
English-5
31/01/2003, 20:47
Protective Sheet
Tabletop Stand
