Parameter
No.
n172 Frequency reference bias
lower limit (UP/DOWN
command 2)
n173 DC Injection Braking
Proportional Gain
n174 DC Injection Braking Integral
Time Constant
n175 Reducing Carrier Frequency
Selection at Low Speed
n176 Constant Copy Function
Selection
n177 Constant Read Selection
Prohibit
n178 Fault History
n179 Software Version No.
Multi-Function Inputs
Value Function
2 Reverse/Stop
3 External fault (NO)
4 External fault (NC)
5 Fault reset
6 Multi-step reference 1
7 Multi-step reference 2
8 Multi-step reference 3
10 JOG command
12 External base block (NO)
13 External base block (NC)
17 Local/Remote selection
Note: Refer to user's manual for full set value listings
EN-18
Description
(100ms)
Factory
Setting
0.0%
83
(0.083)
25
0
(Note5)
rdy
0
-
-
Multi-Function Outputs
Value
0
1
2
6
12
13
15
Analogue Output Functions
Value
0
1
Note: Refer to user's manual
for complete list
1.Not initialized by constant
initialization.
2.Upper limit of setting range and
factory setting are doubled for
400V Class.
3.Depends on inverter capacity.
Refer to user's manual.
4.When control mode selection
(n002) is changed, factory
setting corresponds to the
control mode. Refer to user's
manual.
5.Enabled (1) for 5.5kW and
7.5kW inverters
Function
Fault output
Running output
Frequency agree
Overtorque being Monitored (NO)
Run mode
Inverter ready
Undervoltage in progress
Function
Output frequency
Output current
