Retrofitting and operation of radio control system
Door.control.unit.S55.with.ELS.Professional.Card.can.be.equipped.
with. a. 1-channel. radio. remote. control. system.. If. such. a. system.
has.been.ordered.with.the.control.unit,.the.radio.receiver.will.al-
ready. have. been. installed. in. the. control. unit.. If. this. is. the. case,.
please.proceed.to.the.section."Operation".
If.a.radio.remote.control.system.is.being.retrofitted,.you.must.first.
install.the.receiver.board.on.the.motherboard..For.this.disconnect.
the.entire.door.control.system.from.the.mains.
Insert.the.radio.control.receiver.board.in.slot.J1.at.the.top.right.of.
the.S55.circuit.board,.as.shown.on.the.drawing. Watch.for.proper.
orientation.of.the.board!
Function
1-channel radio remote control
The.1-channel.radio.remote.control.operates.in.the.same.way.as.the.1-way.pushbutton.switch..The.pushbutton.commands.
are.executed.one.after.the.other.in.the.sequence.UP.-.STOP.-.DOWN.-.STOP..If.there.is.a.fault,.the.pushbutton.commands.are.
executed.one.after.the.other.in.the.sequence.UP.-.STOP.-.UP.
Caution
When using a radio control system the person controlling the door must have a clear view of the door and
its surrounding area during door movement and must not be in a dangerous position (see EN12453).
In setting mode and in the event of a malfunction, the radio receiver board must be removed from the PCB
slot J1.
Programming the Hand-held Transmitter Code
The.hand-held.radio.control.transmitter.has.been.coded.by.the.manufacturer..The.radio.control.receiver.must.be.set.to.this.
code..To.program.the.hand-held.transmitter.code.in.the.radio.control.receiver.proceed.as.follows:
•. Press.Program.Channel 1.on.the.radio.control.receiver..The.relevant.red.signal.LED.begins.flashing..You.can.program.the.
hand-held.transmitter.code.within.the.next.15.s.
•. To.do.this.press.the.button.on.the.hand-held.transmitter.for.approx...s..The.programming.of.the.hand-held.transmitter.
code.is.confirmed.by.the.signal.LED.on.the.receiver.staying.on.continuously.
•. Now.let.go.of.the.button.on.the.hand-held.transmitter.
With.the.single.channel.receiver,.you.can.program.a.maximum.of.60.single.channel.remotes.
Note
You can combine all hand-held transmitters with all receivers.
Example:
You have an application with 4 doors each of which is controlled by an S55 with 1-channel radio control
receiver. If you use 4-channel hand-held transmitters and assign each button to one of the 4 receivers,
you can control all 4 doors independently of one another with just one hand-held transmitter.
If you require more than 60 transmitter codes, please contact your dealer. Here too we can offer custom-
ised solutions.
Deleting All the Transmitter Codes Programmed
To.delete.the.hand-held.transmitter.codes.in.the.radio.control.receiver.proceed.as.follows:
•. Press.Program.Channel 1.on.the.radio.receiver.and.keep.it.pressed..The.red.signal.LED.begins.to.flash.slowly..After.approx..
5.s.the.red.signal.lamp.flashes.quickly.
•. Keep.the.button.pressed.until.the.red.signal.lamp.goes.out.
•. When.the.signal.lamp.goes.out,.all.the.codes.of.the.1-channel.radio.control.receiver.have.been.deleted.
•. Only.now.let.go.of.the.button.again.
Radio.control.receiver.
board
