Safety edge

The.following.safety.edge.systems.can.be.connected.to.door.control.unit.S55.directly:
•. Pneumatic.safety.edge.or
•. Electric.safety.edge.or
•. Optoelectronic.safety.edge:.FRABA.OSE
The.sensor.required.is.integrated.into.the.control.unit.(self-monitoring.sensor.as.per.pr.EN.1453).
The.pneumatic.safety.edge.or.the.electric.safety.edge.is.connected.up.to.terminals.7 and.8.(SKS/USA)..It.must.be.connected.
inside.the.pressure.switch.contact.or.at.the.end.of.the.electric.safety.edge.in.accordance.with.the.wiring.diagram.for.the.
S55.
In.the.case.of.factory-assembled.electric.safety.edges,.check.their.terminating.resistance..Safety.edges.with.a.1..kΩ.or.8..
kΩ.terminating.resistor.may.be.used.
Connect.the.OSE.optoelectronic.safety.edge.made.by.FRABA.to.terminals.11,.12.and.13.(OSE).direct.without.the.need.for.any.
terminating.resistor.(11.-.brown.wire,.12.-.white.wire,.13.-.green.wire).
To.adapt.the.control.unit.to.the.respective.safety.edge,.set.DIP.switches.1.1,..1.and...according.to.the.following.table.
Type of safety edge
Pneumatic.safety.edge.1..kOhm
Pneumatic.safety.edge.8..kOhm
Electric.safety.edge.1..kOhm
Electric.safety.edge.8..kOhm
Optoelectronic.safety.edge.FRABA.OSE
Caution
When using optoelectronic safety edge FRABA OSE DIP switch 2.1 must always be set to the OFF position
or else the self-monitoring system of the sensor integrated into the control unit will be deactivated.
If a pneumatic switching rail is used, DIP switch 1.1 must be set to the ON position, as otherwise the func-
tion of the pneumatic rail will not be correctly monitored. When delivered, safety devices may be bridged.
Before initial use, always check that no non-permissible bridging exists.
If.the.safety.edge.responds.during.downward.movement.(bottom.rail.sensor.LED.SKS/USA.lights.up),.the.door.is.stopped.
instantly.by.the.S55.control.unit..After.an.internal.time.of.0.3.s.(time.Z2).has.elapsed,.the.S55.opens.the.door.again..Depend-
ing.on.the.setting.of.DIP.switch.1.3,.the.control.unit.moves.the.door.clear.of.the.obstacle.or.to.the.top.end.limit.
Voltage output for external control devices (Module Card)
AT.the.terminals.+ and.-.on.the."Module.Card".DC.power.is.available.for.external.control.devices:.U.=.4.V.DC,.I
This.voltage.output.is.protected.by.a.fine-wire.fuse.F.with.00.mA.slow-blow.
Partial Opening (only ELS Professional + Module Card)
A.switch.to.activate.the.partial.opening.(also.referred.to.1/.door.height).can.be.installed.to.terminals.StX of the Module
Card..If.Partial.Opening.is.activated,.the.setting.of.limit.switch.S8.(green.cam).of.the.drive.serves.as.the.top.end.limit.
Partial Opening (only ELS Professional + Module Card)
A.switch.for.activation.of."Automatic Closing".can.be.connected.to.terminals.WZL.of.the.Module.Card.
If.Automatic.Closing.is.activated,.the.door.is.closed.by.the.control.unit.after.the.automatic.closing.time.(time.Z4.=.60.s).has.
elapsed..If.the.Early.Warning.function is.activated.(DIP.switch.1.6.in.the.ON.position),.before.commencing.the.automatic.clos-
ing.procedure.an.early.warning.is.given.by.actuating.relay.1.with.an.early.warning.time.Z3.=.3.s.
By. attaching. the. timer. module. to. system. plug. X1. of. the. ELS. Professional. Card. III,. the. reclosing. time. can. be. variably. set.
. b etween..and.40.s.
For.a.description.of.the.timer.module,.see."Timer.Module.Technical.Information"
DIP 1.1 DIP 2.1
ON ON
ON ON
OFF ON
OFF ON
OFF OFF
DIP 2.2
ON
OFF
ON
OFF
OFF
