Ensure that all the adjustments in points 8 and 9
D
below have been performed before continuing.
E
Next, place the guide plate A (Fig. 27) over the piece to be
C
edged B (Fig. 27) and move the pressure roller C (Fig. 27) close
to the piece but without touching it.
F
A
B Hold the machine over the piece with your right hand and move
the edge with your left hand through the guides E (Fig. 27), to
(Figure 27)
the advance roller F (Fig. 27). The edge will be automatically
fed through to pressure roller C (Fig. 27).
When the edge appears between the panel and the pressure
roller C (Fig. 27), allow around 2 cm of edge to pass with res-
(Figure 26)
pect to the panel and press roller C against the edge and the
panel (Fig. 26). The edge will stick and the turning movement
C
B
of the pressure roller will move the machine forward (Fig. 26)
continuously and consistently, at a speed of between 2 and
6 metres/minute according to the difficulty of the piece, and
this can be selected using handle A (Fig. 14). The selected speed
will be shown by the corresponding yellow LED D (Fig. 14).
A
D
(Figure 14)
E
PEB200-PEB250 / Operating instructions - 31
