Virutex PEB250 Gebrauchsanweisung Seite 27

B
A
(Figure 8)
B
C
D
A
(Figure 9)
B
(Figure 10)
C
E
Pass the previously prepared strip through the intake guide B
(Fig. 8). Adjust the height of the edge with knob C (Fig. 8) to
the feeder roller E (Fig. 8). Adjust the edge press B (Fig. 10) to
the corresponding thickness, turning knob B (Fig. 10) and finally
adjust the exit for the edges B (Fig. 9) with knob C (Fig. 9).
Now slowly turn the glue flow control knob A (Fig. 15) anti-
clockwise to open the passage for the glue, completing ap-
proximately half a turn towards "+". Move the edge forward
so that it is caught by the feeder roller E (Fig. 8) and check
when it comes out that the edge is properly and uniformly
glued. If not, readjust the amount of glue using the control
knob A (Fig. 15). In general, this adjustment will only need to
be completed once.
A
With a full glue tank you can glue approximately 35 m of
edge with a height of 25 mm, or 15 m of edge with a height
of 62 mm.
9.2 Controlling the gluing speed. (ONLY PEB250)
With a simple turn of the control, you can regulate the speed
while you continue banding. No need to stop.
To change the speed, you should turn handle A (Fig. 14) until
index C (Fig. 14) is set to the speed you require. Index C shows
the speed in m/min, (2-4-5-6).
The maximum speed is recommended for straight jobs and with
a low edge. The minimum speed is recommended for rounded
shapes with small internal radii and also for tall edges.
The control knob (Fig. 15) should not be moved once
the machine has cooled down. The control knob A
(Fig. 15) can only be moved: PEB250- After hearing
the Beep-Beep noise, and in the PEB200- When LED
C comes on (Fig. 16-1).
PEB200-PEB250 / Operating instructions - 27
