6. Symbols of the Display

Note Fig. 2
1 Ambient temperature
2 Humidity (%)
3 Dew point
4 Surface temperature of the
measured object
5 Laser-Display
6 Temperature unit (C / F)

7. General Specifications

Display
Laser
Power
Wavelength
Response spectrum
emissivity
response time
Optical resolution
Auto power off
Power supply
Operating temperatute
Storage temperature
7 Type K temperature probe
active
8 Infrared temperature
measurement active
9 emissivity
10 Battery icon
11 Data hold
LCD 4-colored with backlight
Laser radiation class 2
< 1mW
630 - 670 nm
8 - 14 µm
adjustable (0.1 to 1.0)
0,5 s
12 : 1 (Note Fig. 3)
ca. 15 s
1 x 9V (6 F 22) Battery(s)
0°C to 40°C (32°F to 104°F)
-10°C to 60°C (14°F to 140°F)
EN 5
