6.

Symbols of the Display

(Note Fig. 2)
1. Date / Time
2. Battery icon
3. Menu
4. Function selection
7.

General Specifications

Display
Range selection
VOP (Velocity of propagation)
VOP-Value
VOP-Storage capacity
Minimum length:
Maximum length:
VOP ≤ 99,9%
VOP ≤ 80,0%
VOP ≤ 66,0%
VOP ≤ 50,0%
Output impedance
Auto Power Off
Power supply
Operating temperature
Storage temperature
Weight
Dimensions
2,4" TFT color - Display
automatically
1,0 % - 99,9%
specified: 20
userdefined: 99
5 m
3.000 m
2.400 m
2.000 m
1.500 m
automatically
adjustable (10 - 60 Min.)
2 x 1,5 V (AA - Battery(s))
0°C to 40°C / <80%
-10°C to 50 °C 7 < 80%
Remove the battery if Humidity >80%
228 g
152 x 61 x 34 mm
EN 5
