Chaser:
Mode:
C7 S1
S2
S3
S4
S5
S6
S7
C8 S1
S2
S3
S4
S5
S6
S7
C9 S1
S2
S3
S4
S5
S6

DMX-CONTROLLED OPERATION

You can control the panels individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.

Addressing the controller

DMX-512:
The wires must not come into contact with each other, otherwise
Only use a stereo shielded cable and 3-pin XLR-plugs and connectors in order to connect the controller with
the fixture or one fixture with another.
Building a serial DMX-chain:
Connect the DMX-output of the controller with the DMX-input of the nearest device. Always connect one
output with the input of the next fixture until all fixtures are connected.
Caution: At the last fixture, the DMX-cable has to be terminated with a terminator. Solder a 120
between Signal (–) and Signal (+) into a 3-pin XLR-plug and plug it in the DMX-output of the last fixture.
Function:
Red solid color, yellow "jumps" to music
Yellow solid color, green "jumps" to music
Green solid color, cyan "jumps" to music
Cyan solid color, blue "jumps" to music
Blue solid color, magenta "jumps" to music
Magenta solid color, red "jumps" to music
varied from S1 – S6
Red solid color, yellow "rolls" to music
Yellow solid color, green "rolls" to music
Green solid color, cyan "rolls" to music
Cyan solid color, blue "rolls" to music
Blue solid color, magenta "rolls" to music
Magenta solid color, red "rolls" to music
varied from S1 – S6
All colors move to music
All colors move to music
All colors move to music
All colors move to music
varied from S1 – S4
All colors randomly move to music
the fixtures will not work at all, or will not work properly.
19/39
Ω
resistor
