Maintenance - Cebora POWER ROD 131 Bedienungsanleitung

4 ERRORS AND SOLUTIONS
ERROR PROBABLE CAUSE
The welding Switch set to 0
machine does
not deliver Mains fuses burnt.
them. current.
Completely Plug not correctly
inoperative. inserted in the
power socket.
The welding Incorrect supply
machine does voltage: yellow
not deliver lamp lit.
current, but the
fan works. Thermostat open:
yellow lamp lit.

5 MAINTENANCE

Any maintenance operation must be carried out by qua-
lified personnel in compliance with standard CEI 26-29
(IEC 60974-4).
5.1 GENERATOR MAINTENANCE
In the case of maintenance inside the machine, make
sure that the switch F is in position "O" and that the
power cord is disconnected from the mains.
It is also necessary to periodically clean the interior of the
machine from the accumulated metal dust, using com-
pressed air.
5.2 PRECAUTIONS AFTER REPAIRS.
After making repairs, take care to organize the wiring so that
there is secure insulation between the primary and secon-
dary sides of the machine. Do not allow the wires to come
into contact with moving parts or those that heat up during
operation. Reassemble all clamps as they were on the origi-
nal machine, to prevent a connection from occurring
between the primary and secondary circuits should a wire
accidentally break or be disconnected.
Also mount the screws with geared washers as on the ori-
ginal machine.
SOLUTION
Set it to 1.
Replace
Insert the plug.
See 2.3
Wait approxima
tely 5/6 min.
See 2.3
9
