Overheat protection

The »Design Multi Juicer« will automatically stop operating if the motor is stalled for more
than 10 seconds. This is a safety feature. Either too much food is being processed at
one time or the pieces are not small enough. Try trimming food, cutting food into smaller
pieces of even size and/or processing a smaller amount per batch. To continue juicing,
reset the appliance by pressing the ›ON/OFF‹ switch on the control panel to ›OFF‹, then
turn the appliance back on by pressing the ›ON/OFF‹ switch to ›ON‹.
DISASSEMBLING YOUR »DESIGN MULTI JUICER«
WARNING: Always turn the appliance off and pull the plug when the appliance is
not in use or when disassembling, moving or cleaning the appliance.
1. Ensure the appliance is turned off by pressing the ›ON/OFF‹ switch on the control
panel to ›OFF‹. Then switch the appliance off at the power outlet and unplug the cord.
2. Remove the pulp container by tilting the pulp container slightly to the right and
unlatch it from under the juicer cover and the container support extending from under the
motor base.
3. Use the grip handle located on the safety locking arm to lift the locking arm from the
juicer cover and lower down out of position.
4. Lift the juicer cover off the juicer.
5. Remove the filter bowl surround with the stainless steel
filter basket still in place. To remove the filter bowl grab it
with both hands and lift it.
6. WARNING:
small sharp blades to cut and process fruit and vegetables.
Do not touch blades when handling the filter basket.
To remove the stainless steel filter basket from the filter bowl
surround, insert fingers under the grooves market 'LIFT BAS-
The stainless steel filter basket contains
51
