Cushion nozzle

Assembly

Unpacking the product contents

ATTENTION!
❐ Risk of suffocation! Keep the packaging material away from children and animals.
❐ Make sure that the device is not connected to the power supply before you attach or
remove any accessories.
• Unpack all parts and make sure that the scope of delivery is complete (see chapter
"Product contents and device overview") and check for any damages from transport.
If you identify damages to the components, do not use them (!), instead contact our
customer service centre.
• If necessary, remove any piece of paper or sticker etc. from the dust bin. In chapter
„Cleaning the Device" you will fi nd instructions on how to remove and open the dust bin.

Inserting/removing the hose

Inserting/removing the telescoping tube

Adjusting the length of the telescoping tube

The cushion nozzle is suitable for cleaning sensitive
objects and cushions, e.g. lamp shades, sofas etc.
• Insert the suction hose connector into the suction opening
on device (see arrow). It must audibly lock into place.
• To remove the suction hose push the knob on the connec-
tor and pull the suction hose out.
• Insert the open end of the handle into the corresponding
opening on the telescoping tube. In the process, turn the
handle back and forth somewhat. Check to make sure
that the connection is secure.
• To remove the telescoping tube pull it off of the handle.
• Push the slider on the telescoping tube down and set the
desired length.
• Release the slider and move the tube forward until it locks
into place.
24
