Rear view

15
14
10 Release button for dust bin
11 Button for cable winder
12 Suction power control
13 Mains plug
14 Bracket for hooking in the fl oor nozzle
15 On/Off switch
Not shown:
Exhaust fi lter compartment with HEPA-fi lter (below the dust bin)

Suction nozzles

ATTENTION!
❐ Always turn off the vacuum cleaner fi rst before changing the nozzles.
Floor nozzle
Crevice and Brush Nozzle
The fl oor nozzle is suitable both for carpets and smooth
fl oors.
With the foot switch, you can switch between a smooth
fl oor and a carpet. A brush is deployed on the device
bottom for smooth fl oors.
Fold over the end piece in the direction of the arrow to
convert the crevice nozzle into a brush nozzle:
The crevice nozzle is suitable for upholstery, cleaning the
inside of cars and for all nooks and crannies that cannot
be reached with the other nozzles.
The brush nozzle is suitable for all uneven objects, furni-
ture, lamps, profi les and skirting boards, window ledges,
etc.
