DK
Ved brug af forlængerledninger
Brug udelukkende godkendte forlæn gerledninger, der er beregnede til maskinens effekt.
D
Lederne skal have et gennemsnit på mindst 1.5 mm
en tromle, rulles ledningen helt af.
NL
3. MONTAGE OG INDSTILLINGS FORSKRIFTER
Inden indstillingen af rundsaven påbegyndes, skal du forvisse dig om, at stik-
F
ket er trukket ud af stikkontakten.
E
Indstilling af savevinkel (skråvinkel)
Fig. B
P
•
Løsn begge knapper (12).
•
Drej bundpladen i den korrekte position (0° - 45°) og stram knapperne igen.
Savevinklen (skråvinkel) kan aflæses på vinkelmåleren (14).
I
Montering af kløveanlægsfladen
Fig. C
S
•
Løsn knappen (11).
•
Sæt kløveanlægsfladen i de forhåndenværende spalter.
•
Indstil den korrekte skærebredde og stram knappen igen (11).
SF
Indstilling af skæredybde
Fig. D
N
•
Løsn knappen (3).
•
Før bundpladen (7) nedad.
•
Savklingens skæredybde kan aflæses på siden af sikkerhedsskærmen.
DK
•
Stram spændeknappen (3) igen, når den korrekte dybde er indstillet.
Udskiftning eller rengøring af savklingen
Fig. E
•
Brug aksellåseknappen (13) for at forhindre akslen i at dreje.
•
Løsn derefter sekskantskruen (6) midt i savklingen, med den medfølgende seks-
kantnøgle.
•
Drej sikkerhedsskærmen tilbage, og hold den der ved hjælp af knappen (15).
•
Træk stopringen og savklingen ud og gør savklingen ren eller udskift den med en ny.
•
Sæt igen savklingen tilbage på akslen.
•
Lad sikkerhedsskærmen vende tilbage over savklingen ved at løsne knappen (15).
•
Tryk aksellåseknappen (13) i igen, monter stopringen (8) igen og stram sekskantskru-
en (6) godt igen.
4. BETJENING
Det anbefales at bruge høreværn, når der arbejdes med rundsaven.
98
2
. Hvis forlængerledningen sidder på
Ferm
Wear ear and eye protection
Faulty and/or discarded electrical or electronic apparatus have to be collected
at the appropriate recycling locations.
Danger
a) Keep hands away from cutting area and the blade. Keep your second hand on auxili-
ary handle, or motor housing. If both hands are holding the saw, they cannot be cut
by the blade.
b) Do not reach underneath the workpiece. The guard cannot protect you from the blade
below the workpiece.
c)
Adjust the cutting depth to the thickness of the workpiece. Less than a full tooth of the
blade teeth should be visible below the workpiece.
d) Never hold piece being cut in your hands or across your leg. Secure the workpiece to
a stable platform. It is important to support the work properly to minimize body expo-
sure, blade binding, or loss of control.
e) Hold power tool by insulated gripping surfaces when performing an operation where
the cutting tool may contact hidden wiring or its own cord. Contact with a "live" wire
will also make exposed metal parts of the power tool "live" and shock the operator.
f)
When ripping always use a rip fence or straight edge guide. This improves the accu-
racy of cut and reduces the chance of blade binding.
g) Always use blades with correct size and shape (diamond versus round) of arbour
holes. Blades that do not match the mounting hardware of the saw will run eccentri-
cally, causing loss of control.
h) Never use damaged or incorrect blade washers or bolt. The blade washers and bolt
were specially designed for your saw, for optimum performance and safety of opera-
tion.
Causes and operator prevention of kickback
•
Kickback is a sudden reaction to a pinched, bound or misaligned saw blade, causing
an uncontrolled saw to lift up and out of the workpiece toward the operator;
•
When the blade is pinched or bound tightly by the kerf closing down, the blade stalls
and the motor reaction drives the unit rapidly back toward the operator;
•
If the blade becomes twisted or misaligned in the cut, the teeth at the back edge of
the blade can dig into the top surface of the wood causing the blade to climb out of
the kerf and jump back toward the operator.
Kickback is the result of saw misuse and/or incorrect operating procedures or conditions
and can be avoided by taking proper precautions as given below.
a) Maintain a firm grip with both hands on the saw and position your arms to resist kick-
back forces. Position your body to either side of the blade, but not in line with the
blade. Kickback could cause the saw to jump backwards, but kickback forces can be
controlled by the operator, if proper precautions are taken.
b) When blade is binding, or when interrupting a cut for any reason, release the trigger
and hold the saw motionless in the material until the blade comes to a complete stop.
Ferm
GB
D
NL
F
E
P
I
S
SF
N
DK
07
