Wind sock horizontal

Immediate indicator for the onset of rain

- When the onset of rain is detected, this is reported to the base station the next
time data is wirelessly transmitted and is indicated by a rain cloud in the "RAIN"
field and Weather Joe's open umbrella.

Comfort indicator

- The comfort indicator (LKJ) reflects the interior climate (the temperature related
to the humidity). A table of values for the display ranges can be found in the Ap-
pendix.

Trend indicator (history)

- The bar graph shows the barometric pressure, outside temperature or inside
temperature trend over the last 24 hours. The individual columns do not represent
absolute values; rather, they show the difference to the current measured value
(0 h column). This reference point is always of a medium height (4 bars) so that the
trend can be identified immediately.

Data memory

- If the data memory is almost full, the following message will appear in the menu
line:
MEMORY ALMOST FULL
- Touch this input area to acknowledge it and read the collected data out via the PC.

Transmitting data to the combination sensor, "WAIT FOR TRANSMISSION"

- If "WAIT FOR TRANSMISSION" appears in the menu line, the weather station is
transmitting data to the combination sensor, activating live mode or sending confi-
guration data relating to hours of sunshine, for example.
This procedure can take a few minutes, during which time the weather station
cannot be operated.

Temperature trend indicator

- An arrow indicating the trend will appear to the right of the temperature data in the
"Indoor" and "Outdoor" display fields if the temperature has increased (arrow poin-
ting up) or decreased (arrow pointing down) during the latest transmission interval.

Sensor status indicator

- In the outdoor sensor display field ("Outdoor"), a small reception indicator shows
the status of the sensor:
→ Strong wind (>20 km/h)
OK
