4.2

Operation

As all relevant data appears on the display at the same time, operation is essentially
restricted to simply selecting other sensors or additional weather data by lightly
touching the corresponding display field.
The display is divided into the display field and the menu line (device main menu
displayed):
MIN MAX
In normal mode the following functions can be accessed by touching the correspon-
ding fields on the display:
INDOOR:
OUTDOOR:
HUMIDITY:
SENSOR:
RAIN:
SUNSHINE DURATION:
TIME/DATE:
WIND:
AIR PRESSURE:
HISTORY:
WEATHER SYMBOL FIELD:
54
RESET
Toggle between displaying the temperature and the dew
point ("DEWPOINT")
Toggle between displaying the temperature, the dew point
and the wind chill temperature
No function
Toggle between the external sensors:
1...8: HM-WDS10-TH-O, HM-WDS30-T-O or
HM-WDS40-TH-I
No display: HM-WDS100-C6-O
Toggle between the total rainfall since the last reset
("total"), rainfall for the current hour ("current 1h"), the last
hour ("1h"), the current day ("current 24h") and the previous
day ("24h"); hourly values recorded at 30 minutes past the
hour; daily values at 07:30 on the day in question
Toggle between hours of sunshine for the current day ("h/day")
and the total hours of sunshine since the last reset ("h")
No function
Toggle the numerical display between wind velocity in
km/h, m/s, mph and wind direction in degrees
Toggle the display of barometric pressure between the
pressure measured at the location ("absolute") and the
pressure at sea level calculated from that measured value
("relative")
Toggle the trend indicator for the last 24 hours between
the barometric pressure, inside temperature and outside
temperature (of the sensor shown); refer also to point 26
on page 46
No function
