- Touch "ENTER" and the following appears:
SENSOR
- Touch "SENSOR" repeatedly to select the memory slot where the desired sensor
is to be saved. Please note that the HM-WDS100-C6-O can only be saved to the
"COMBI-SENSOR" memory slot.
- Then select "ADD" and the following appears (example for sensor 1):
SENSOR
- The desired sensor now needs to be taught-in. To do this, insert the batteries in the
corresponding sensor and press its teach-in button. If "USED" appears in under
one second, the sensor has been taught-in correctly.
Data from the HM-WDS100-C6-O appears automatically (after a maximum of 6
minutes) in the corresponding areas of the display; data from the other sensors
appears as per the memory slot selected in the "OUTDOOR" display field ("Sensor"
field).
Identification of assigned memory slots
Memory slots that have already been assigned are identified by "USED" after the
memory slot number.
However, this label does not indicate whether the corresponding sensor is actually
active or not. This will only become apparent if no data is provided or out-of-date
information is supplied when the sensor is selected and the reception indicator in
the "OUTDOOR" field is active.
Deleting a sensor's assignment
If necessary, a sensor's serial number can be deleted from the sensor memory.
- First proceed as described under "Teaching-in", then select the desired sensor
and, instead of touching "ADD", touch the "DEL" option.
- "USED" is deleted from after the sensor number, making the memory slot available
for registering a different sensor.
Tip for starting up sensors
In order to start sensors up properly, they can first be activated in the vicinity
of the weather station.
However, there must be at least 1 m between the sensor and the weather station
in order to prevent malfunctions.
NO 1
NO 1 - - SYNC
ADD DEL
ADD DEL
