2. Latch the base support onto the clip
on the glass base and sit it down on
the two screw domes.
3. Use the hexagon wrench and two
hexagon socket screws supplied
to screw the base support onto the
glass base. When doing this, make
sure that the lighting cable from the
device base is routed to the side as
shown in the photo, so it does not
become pinched.
4. Attach the weather station to the
clips on the base support and swivel
it onto the base support until the
screw domes sit properly in the
corresponding receptacles on the
weather station.
Caution!
Do not let go of the weather
station until the two hexagon
socket screws have been inserted
(see the next step). When holding
the weather station, do not touch
the display. Only hold the weather
station by its surround.
