- Select the "SYSTEM" menu then the "ALTITUDE" option (via BEEP, DCF, DST and
INTERVAL) and the following appears:
ALTITUDE
- Touch "ENTER" and the following appears:
ALTITUDE
- Touch "+" or "-" to set the geographical height of the location above sea level in
metres.
- Wait for a few seconds. The adjusted data for the relative barometric pressure will
then appear on the display.
Alternatively, the value can also be entered via the PC program.

"RAIN CAL", entering the rain sensor adjustment value

The rainfall measuring system is factory-set to a high degree of accuracy, so it does
not usually need to be adjusted.
The adjustment value must first be calculated in normal mode, as described in the
section titled "Adjusting the rainfall measuring sensor".
- Select the "SYSTEM" menu then the "RAIN CAL" option (via BEEP, DCF, DST,
INTERVAL and ALTITUDE) and the following appears:
RAIN CAL
- Touch "ENTER" and the following appears:
RAIN CAL
- Touch "+" or "-" to set the previously calculated value.
- Wait for a few seconds. The device will then return to normal mode.
Alternatively, the value can also be entered via the PC program.

"SUN CAL", configuring the brightness threshold for hours of sunshine

The WDC7000 weather station works in conjunction with the WDS100-C6-O combi-
nation sensor to determine the hours of sunshine. The threshold value is set on the
base station and transmitted to the combination sensor. This sensor then evaluates
the data:
Brightness received at sensor greater than threshold value → sun shining
Brightness received at sensor lower than threshold value → sun not shining
62
ENTER
+ 0000 -
ENTER
+ 295 -
