Maxxus BX 7.0 R Bedienungsanleitung Seite 27

Teileliste
Teile-Nr. Bezeichnung
71 M8x15mm Hex Head Screw
72 M8x20mm Hex Head Screw
73 M8x20mm Hex Head Screw
74 M8x 45mm Hex Head Screw
75 M8x 57mm Hex Head Screw
76
M8x 65mm Hex Head Screw
77 M8x 40mm Hex Head Screw
78 M20xP1.0x12t Hex Nut
79
M10xP1.25 Crank Nut
80 6mm Hex Nut (Black)
81 6mm Hex Nut (Silver)
82 6mm Nylon Nut (Silver)
83 M8 Nylon Nut (Thin
84 M8 Nylon Nut (Thick)
85
M8 Nut Cap
86 3/8" x26 Acorn Nut Cap
87 5x16x2.2t Washer
88 6x16x1.0t Washer
Menge
18
1
4
4
2
2
2
1
2
2
2
4
)(Black) 4
(Black) 7
4
2
8
8
Teile-Nr. Bezeichnung
89 8x18mm Curve Washer
90 8x16x1.5t Washer
91 8x16x3.0t Washer
92 8x19x1.0t Washer
93 10x19x2.0t Washer
94 20x30x1.0t Washer
95 20x30x2.0t Washer
96 Monitor
97 Mag Brake
98 Drive Cable
99 Magnet
100 Senor Wire with sensor
101 DC Power cord
102 Gear Box
103 Gear Box Wire
Middle Extension pulse wire
104
105 Rear Extension pulse wire
106 Upper Extension pulse wire
107 Extension Wire
108 Hand Pulse Sensor w/Wire
Menge
1
12
4
23
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
