Clearing Jammed Staples
It may otherwise accidentally be triggered after removing the staple.
Note: Set the On / Off switch
jammed staple.
Open the magazine
Remove the jammed staple from the magazine
Note: Do not trigger the staple gun when empty to prevent wear.
Determining the Staple Length
Consider two factors when determining the correct staple length:
- the thickness of the material being stapled
- the composition (hardness) of the material being stapled.
Staples 4–6 mm in length will typically suffice when stapling into hard
materials such as hardwood.
Staples 8–10 mm in length will typically suffice when stapling into soft
materials such as softwood. This should suffice to fasten any materials.
The crown of the staple should be flush with the top of the material
being fastened as shown.
If the crown of the staple is not flush with the top of the material being
fastened, the staple is too long. In this case, use the next smaller size
staple for optimal results.
18 GB
If a staple is jammed, do not squeeze the trigger
to "O" position prior to clearing the
8
and pull back on the pusher
4
1
.
3
.
4
.
