Menu Configuration (cont.)
Remote Setting
Settings for the external control.
Item To do
Parallel Type Select a control method of the MAKE/TRIGGER terminal.
Pin1
Pin2
Assign the control functions to the pins of the MAKE/TRIGGER terminal.
Pin3 • Assign a function to each pin terminal by selecting "Set" in "Parallel Type" mentioned
above.
Pin4
Pin5
Pin6 The functions are assigned for "Pin6" – "Pin8" and you cannot change the assignment of
these functions.
Pin7
Pin8
Information
Settings for the information display of the monitor.
Item To do
Source ID
Select whether the name assigned in "Character Setting" (☞ below) is displayed on the
screen (☞ "On the Information Display" on page 11).
• When "Auto" is selected, the display color synchronizes with the color of the tally lamp
while the tally lamp is lit.
Character Setting Assign a name to each video source as you like (10 characters at maximum). You can also enter a name using the RS-232C
system. (☞ Page 22)
Status Display
Display/Hide the status of the current input and the setting of MUTING. (☞ "On the Status
Display" on page 12)
Time Code Display/Hide the Time Code.
Time Code Select Select the type of the TIME CODE display.
CRC Error
Display/Hide the CRC error when the HD SDI signal is input. (☞ "On the Information Display"
on page 11)
Sub Hour Meter Display the hours of use (unit: hour). The usage time can be reset to 0.
Model Display the model name of the monitor.
Version Display the version of the monitor.
Hour Meter* 2 Display the total hours of use (unit: hour). This item is used for maintenance of the monitor. You cannot reset this item.
* 1 Ancillary time code
* 2 "Hour Meter" and settings specified using the Picture adjustment knob

Control Lock*

3
Settings for disabling the buttons on the front panel.
* 3 • The following operations are not available when "Volume Lock" is selected.
- Picture adjustment knob
• The "All Lock" function disables to control the buttons on the front panel. But following operations are available.
- Turning on/off (on standby) the monitor
- Displaying the Set-Up Menu by pressing
- Operating the monitor by an external control
If you try other operations, "Control lock on!" appears on the screen.
Language
Setting values: English, Deutsch, Français, Español, Italiano, Pуccкий
Select the displayed language for the menu, etc.
20
Setting values: Off, Volume Lock, All Lock
button while holding
(☞ 4 on page 10)
are not reset.
button and turning "Control Lock" to "Off"
Setting value
Make, Trigger, Set
☞ "Display" in "Functions
controlled by the MAKE/
TRIGGER system" on page 24
Tally
Enable
GND
Setting value
Off, On, Auto
Auto, Off, On
Off, On
VITC* 1 , LTC* 1 , D-VITC
Off, On
