IMPAC pyrometer IGA 320/23
Internal temperature:
Max. internal
temperature:
Limit switch SP1:
Mode
Limit switch SP1:
Hysteresis
Limit switch SP1:
Error status:
LED aiming light:
LED aiming light at
Power-on
Reading parameters:
Device type:
Serial number:
Device type /
software version:
Detailed Software
version:
Reference number:
Note: the letter "l" means the lower case letter of "L".
Additional instructions for the RS485 interface:
Requirements to the master system during half-duplex operation:
1. After an inquiry, the bus should be switched into a transmission time of 3 bits
(some older interfaces are not fast enough for this).
2. The pyrometer's response will follow after 5 ms at latest.
3. If there is no response, there is a parity or syntax error and the inquiry has to be repeated.
AAgt
Output: XXX (dec. 000 ... 099°C, 032 ... 210°F)
AAtm Output: XXX (dec. 000 ... 099, always in °C)
AAs1XXXX
XXXX = set Limit switch, hex 4-digit, °C or °F
AAt1X
X = 0 Limit switch Off
X = 1 Limit switch close above
X = 2 Limit switch close below
AAhlXX
XX = set hysteresis, hex 2-digit, °C or °F
AAfs Output: XX;
AAlaX
X = 0 switch off aiming light
X = 1 switch on aiming light
AAlpX
X = 0 aiming light off at Power-on
X = 1 aiming light on at Power-on
AApa Output 11-digit, decimal:
AAna Output: "IGA 320" (16 ASCII-characters)
AAsn Output: XXXXX (dec. 5-digit)
AAve Output: XXYYZZ (6-digit decimal)
AAvs tt.mm.yy XX.YY
tt = day; mm = month; yy = year; XX.YY = software version
AAbn Output: XXXXXX (hex 6-digit)
XX=00...FF (00 = no error)
(01...FF: error code for LumaSense service)
Digit 1 und 2 (10...99 or 00): Emissivity
Digit 3 (0 ... 6): Exposure time
Digit 4 (0 ... 8): Clear time max. / min. value storage
Digit 5 (0 ... 1): Analog output
Digit 6 und 7: (00 ... 98): Internal temperature
Digit 8 und 9 (00 ... 97): Address
Digit 10 (0 ... 6 or 8): Baud rate
Digit 11 always 0
XX = 56 (IGA 320)
YY = Month of software version
ZZ = Year of software version
