Manual zoom mode
In the case of cameras from Group A or when using a lens without CPU (for
example, manual focus lens), the zoom position of the main reflector
adjusted manually to the lens focal length. In this case auto-zoom mode is not
possible! After switching on the flash unit, „Zoom" appears in the display and
the current zoom position of the main reflector
Setting procedure
• Press button combination „Select" until „Zoom" appears flashing next to the
zoom position (mm).
• Apply the setting desired with the buttons ( + ) and ( - ). The flashing display
changes to „M.Zoom" for manual zoom mode. The following zoom positions
are possible for the main reflector:
24 - 28 - 35 - 50 - 70 - 85 - 105 mm (35 mm format).
The setting takes effect immediately. After about 5 seconds the display stops
flashing and the setting is saved automatically.
When the camera transmits the lens focal length to the flash unit and a
manual zoom setting results in the shot not being completely lit by the
main reflector (for example, spot effect), the display of the zoom position
of the main reflector flashes as a warning!
Tip:
If you do not necessarily need the full guide number and maximum flash range
of the flash unit, you can leave the zoom reflector at the position for the shortest
focal length of the zoom lens. This will provide full light coverage of the picture
and eliminate the need to continually adjust it to the focal length of the lens.
Example:
You use a zoom lens with a focal length range of 35 mm to 105 mm. In this
case, you set the position of the main reflector of the flash unit to 35 mm.
78
Resetting to auto-zoom
• Touch the shutter release to begin a data transfer between the flash unit and
must be
• Press the button combination „Select" until „M.Zoom" appears flashing next to
appears.
• Press the button ( + ) until the 105 mm position has been exceeded. The flas-
Wide-angle diffuser
With the wide angle diffuser
nated (35 mm format).
Pull the wide-angle diffuser
and then release it. The wide-angle diffuser
The main reflector
readings and the zoom value are corrected to 18 mm on the display panel.
To insert the wide-angle diffuser
in.
Mecabounce 58-90
If the Mecabounce 58-90 (optional accessories, see 17) is fitted to the main
reflector j of the flash unit, the main reflector is automatically guided to the posi-
tion required. The distance data and zoom factor are corrected to 16 mm.
9.2 Remote slave flash mode (
The flash unit supports the wireless Nikon remote system in slave flash mode
and is compatible with the Nikon system „Advanced Wireless Lighting". Here
the camera.
the zoom position (mm).
hing display „M.Zoom" changes to „Zoom" (= auto-zoom mode) and the
zoom position of the main reflector
focal length. The setting takes effect immediately. After about 5 seconds the
display stops flashing and the setting is saved automatically.
The return from manual zoom mode to auto-zoom mode also occurs if
the flash unit is switched on again with the main switch
, focal lengths of 18 mm or more can be illumi-
out from the main reflector as far as it will go,
automatically moves to the required position. The distance
, turn it upwards 90° and push it all the way
SL
is automatically adjusted to the lens
.
automatically folds downwards.
)
