• Press the button ( + ) until the 105 mm position has been exceeded. The flas-
hing display „M.Zoom" changes to „Zoom" (= auto-zoom mode) and the
zoom position of the main reflector
focal length. The setting takes effect immediately. After about 5 seconds the
display stops flashing and the setting is saved automatically.
The return from manual zoom mode to auto-zoom mode also occurs if the
flash unit is switched on again with the main switch
Wide-angle diffuser
With the wide angle diffuser , focal lengths of 18 mm or more can be illumi-
nated (35 mm format).
Pull the wide-angle diffuser out from the main reflector as far as it will go, and
then release it. The wide-angle diffuser
main reflector automatically moves to the required position. The distance rea-
dings and the zoom value are corrected to 18 mm on the display panel.
To insert the wide-angle diffuser
in.
Mecabounce 58-90
If the Mecabounce 58-90 (optional accessories, see 17) is fitted to the main
reflector of the flash unit, the main reflector is automatically guided to the
position required. The distance data and zoom factor are corrected to 16 mm.
9.2 Remote slave flash mode (
The flash unit supports Canon`s wireless E-TTL Remote System in slave flash mode.
At the same time, one or more slave flash units can be remotely controlled from one
master or controller flash unit on the camera (e.g. mecablitz 58 AF-1C digital).
A slave flash unit can be assigned to one of three possible slave groups (GROUP
A, B or C). The master or controller flash unit can control all of these slave
groups simultaneously and at the same time take the settings for each slave
group into account.
is automatically adjusted to the lens
.
automatically folds downwards. The
, turn it upwards 90° and push it all the way
SL
)
So that multiple remote systems in the same room do not interfere with one anot-
her, there are four independent remote channels available (CH 1, 2, 3 or 4).
Master, controller and slave flash units belonging to the same remote system must
be set to the same remote channel. The slave flash units must be able to receive
the light from the master or controller flash unit with the integrated sensors for
the remote mode .
Depending on the camera model, the camera's internal flash unit can also
function as master or controller flash unit. Please consult the respective
camera operating instructions for further tips on setting the master or con-
troller flash unit.
Setting procedure for remote slave flash mode
• Press the button combination „Select" until „
• Apply the setting desired with the buttons ( + ) and ( - ).
- When „On" is displayed, the remote slave mode is activated.
- When „OFF" is displayed, the remote slave mode is deactivated.
The setting takes effect immediately. After about 5 seconds the display stops flas-
hing and the setting is saved automatically. After activation of the remote slave
SL
mode, „ " appears in the display. In addition, the slave group (GROUP) selec-
ted and the remote channel (CH) are shown.
Setting of the slave group
With the remote slave mode activated, press the button combination „Select"
until „GROUP" (= slave group) flashes in the display. Apply the setting desired
with the buttons ( + ) and ( - ). Selection of group A, B or C is possible.
The setting takes effect immediately. After about 5 seconds the display stops flas-
hing and the setting is saved automatically. After activation of the remote slave
SL
mode, „ " appears in the display. In addition, the slave group (GROUP) selec-
ted and the remote channel (CH) are shown.
SL
" flashes in the display.
