Contents
Description
General information ................................................................ 5
Removing the locomotive from the packaging ....................... 6
Fitting additional parts ........................................................ 6, 7
Maintenance works
• 1. Lubricating ..................................................................... 7
• 2. Dismantling housing .................................................... 12
• 3. Exchanging the circuit board ........................................ 12
• 4. Changing the bulb ........................................................ 12
• 5. Exchanging the motor .................................................. 12
• 6. Maintenance work on the upper gear part .................... 12
• 7. Maintenance work on wheel sets, exchanging lower
gear part and traction tires ........................................... 13
• 8. Exchanging coupler pocket
• 9. Exchanging the pick-up, alternating current ................. 13
• 10. Exchanging the digital decoder in the alternating
current model
• 11. Retrofitting and reprogramming to digital operation .... 14
Spare parts list
direct current and alternating current ........................... 16 - 19
Order example ...................................................................... 20

General assembly and safety information

• These operating instructions describe all work steps
necessary for maintenance and repair. Please read these
operating instructions carefully before you start with your
work.
• In the case of incorrect handling of electrical components,
they may be destroyed. Please ask your specialist dealer to
help with the necessary work (e.g. changing circuit boards).
• In the case of maintenance work, the disassembly is
described below, to re-assemble the tractor reverse the work
steps.
• The maintenance work described below is virtually identical
for direct current and alternating current models. If there are
any differences these will be pointed out specifically.
........................................................................
5
.................................................
Page
13
13
