Relay outputs:
Max. voltage ................................................ 250 VRMS
Max. current ................................................ 2 A / AC
Max. AC power ........................................... 500 VA
Max. current at 24 VDC............................... 1 A
Sensor error detection ................................ Break / Make / Hold / None
EEx / I.S. approval - 5116B:
KEMA 04ATEX1316 X .................................
Applicable for zone ..................................... 0, 1, 2, 20, 21 or 22
Ex / I.S. data for 5116B:
U ............................................................... : 253 V
m
U , Loop Link ............................................. : 60 V
m
Ex / I.S. data for temperature / bipolar mv input:
Terminal 41, 42, 44 and 43
U ................................................................ : 7.5 V
o
I .................................................................. : 2.2 mA
o
P ................................................................ : 4.2 mW
o
C ................................................................ : 6 µF
o
L ................................................................. : 1.0 H
o
Ex / I.S. data for unipolar mA / v input:
Terminal 51, 52 and 53
U ................................................................ : 7.5 V
o
I .................................................................. : 2.2 mA
o
P ................................................................ : 4.2 mW
o
C ................................................................ : 6 µF
o
L ................................................................. : 1.0 H
o
Ex / I.S. data when using 2-wire supply / reference voltage:
Terminal 51, 52, 53 and 54
U ................................................................ : 28 V
o
I .................................................................. : 93 mA
o
P ................................................................ : 650 mW
o
IIC
C o :
75 nF
L o :
3 mH
IIB IIA
645 nF 2 µF
16 mH 31 mH
II (1) GD
[EEx ia] IIC
