Alternating current motor
• The mains supply must have 220÷240 V /
50 Hz.
• Extension cables up to 25 meters long must
have a cross-section of 1.5 mm², those
longer than 25 meters a cross-section of 2,5
mm².
• The mains supply must be secured up to 16
ampere.
When dealing with problems with the machine, unplug it!
Only specialized electricians may do electro-technical maintenance!
Problem
Motor does not start
Incorrect motor rotational di-
rection
When switched off the saw
does not brake
Saw blade jams
In case of problems which you cannot solve yourself, please consult sheppach's customer service department.
Connections and repairs to the electrical
equipment should only be done by an electri-
cian.
For further questions please give the following
information:
• Motor manufacturer, motor type
• Kind of current used
• Data on the machine type label
• Data regarding the electrical connections
When returning the motor, please always send
in the complete drive unit with the electrical
connections.
Trouble shooting
Possible Cause
a) no current
b) Switch or compensator defective
c) Electrical extension cables defective
Incorrectly installed
Braking unit defective
a) The wood is pushed into the saw too quickly
b) saw blade is dull
Solution
a) Check the safety fuse
b) Have an electrician check the unit
c) Unplug the machine, check the cables and, if necessary replace
them
Change the rotational direction via the CEE plug
Replace the braking unit
a) Push the wood in more carefully
b) Use a new saw blade from the scheppach offerings
