Fig. 11
Firmly tighten the wheel assembly in the position where
the wheels slightly touch the ground.
Fig. 12 / 12.1
Fasten the riving knife in line with the saw blade as de-
scribed in the illustration. Slightly release the bolt without
removing it. Retighten it firmly after resetting. For doing
this, it is necessary to remove the saw blade insert (19,
Fig. 13).
Fig. 13
After setting the riving knife, refasten the saw blade in-
sert (19) with 4 countersunk bolts M6 x 16.
Rys.11
Wózek w tej pozycji mocno dokręć, tak, aby kółka lekko
poruszały się po ziemi.
Rys.12 /12.1
Zamontuj klin rozdzielający do piły tarczowej tak, jak jest
pokazane na rysunku. Śrubę lekko poluzuj, (ale całkowi-
cie nie odkręcaj), po ustawieniu znowu mocno dokręć.
Przekładka tarczy piły (19, rys.13) musi być w tym czasie
usunięta.
Rys.13
Po nastawieniu klina rozdzielającego, ponownie przymo-
cuj przekładkę piły tarczowej (19) za pomocą śrub o pła-
skich głowicach M6 x 16.
27
