Anschluss

Anschluss .............................................................................................................. Schraubklemmen
Nennstrom ...............................................................................................................................≤10 A
Anschlussvermögen:
starr / flexibel / Leitergrößen AWG.............................. 0,2...4 / 0,2...2,5 mm
Mehrleiteranschluss (2 Leiter gleichen Querschnitts):
starr / flexibel ...................................................................................... 0,2...1,5 / 0,2...1,5 mm
Abisolierlänge.......................................................................................................................... 8 mm
Anzugsdrehmoment ................................................................................................. 0,5...0,6 Nm
Anschluss .................................................................................................................. Federklemmen
Nennstrom ...............................................................................................................................≤10 A
Anschlussvermögen:
starr ............................................................................................. 0,2...2,5 mm
flexibel ohne Aderendhülse ...................................................... 0,75...2,5 mm
flexibel mit Aderendhülse .......................................................... 0,2...1,5 mm
Abisolierlänge........................................................................................................................ 10 mm
Öffnungskraft ............................................................................................................................ 50 N
Testöffnung, Durchmesser ................................................................................................... 2,1 mm
Sonstiges
Betriebsart..................................................................................................................... Dauerbetrieb
Einbaulage ............................................................................................................................ beliebig
Schutzart, Einbauten (DIN EN 60529) ....................................................................................... IP30
Schutzart, Klemmen (DIN EN 60529) ........................................................................................ IP20
Gehäusematerial.......................................................................................................... Polycarbonat
Entflammbarkeitsklasse .................................................................................................... UL94 V-0
Schnellbefestigung auf Hutprofilschiene......................................................................... IEC 60715
Schraubbefestigung ................................................................................... 2 x M4 mit Montageclip
Gewicht .............................................................................................................................. ca. 150 g
Abweichende Daten Option „W"
Mechanische Beanspruchung nach IEC 60721:
Ortsfester Einsatz (IEC 60721-3-3) .......................................................................................... 3M7
Bestellangaben
Typ/Type Versorgungsspg./Supply voltage U
IR425-D4-1 DC 9,6...94 V / AC 16...72 V, 15...460 Hz
IR425-D4-2 DC 70...300 V / AC 70...300 V, 15...460 Hz
IR425-D4W-1 DC 9,6...94 V / AC 16...72 V, 15...460 Hz
IR425-D4W-2 DC 70...300 V / AC 70...300 V, 15...460 Hz
Montageclip für Schraubmontage (1 Stück je Gerät, Zubehör) / Mounting clip for screw fixing (1 piece per device, accessories)
*Absolutwerte des Spannungsbereichs
Option „W"
Die Geräte mit der Endung „W" entsprechen erhöhter Schock-
und Rüttelfestigkeit. Durch eine besondere Lackierung der
Elektronik wird ein höherer Schutz gegen mechanische
Belastung und gegen Feuchtigkeit erreicht.
