Assembly of Toddler Seat
10
19
20
18
18
17
11
24
6
22
21
12
100 O
22
13
24
Adjusting the 5-point harness
• Bring crutch strap (17) forward between the child's legs and up
toward the front of the waist. Insert the waist straps (18) into the har-
ness buckle until they "click" into place. Make sure the waist straps
are correctly fastened
• Adjust all straps using the sliders (19)
• To release the shoulder and waist straps, press the buttons (20) in
the centre of the harness buckle
Attachment points are provided at the ends of each waist strap for a
separate harness complying with BS 6684.
WARNING!
Make sure that the strap is correctly assembled in the Toddler Seat.
23
Always secure your child with the harness.
Adjusting the backrest on the Toddler Seat
• To adjust the backrest and to fold/unfold the Toddler Seat, loosen
the large knobs (22) on both sides of the seat. Then adjust the angle
of the backrest (23) and tighten the knobs again
Folding of the Toddler Seat
• To fold the Toddler Seat loosen the large knobs on both sides of the
seat and then fold the seat against the footrest of the seat unit (24).
Fold the stroller as normal according to the pram manual
WARNING!
• Never adjust the backrest when a child is placed in the Toddler Seat
• When you fold/unfold the Toddler Seat, make sure that the large
knobs are firmly tightened and that the backrest is placed into posi-
tion.
• When the Toddler Seat is not in use make sure it is folded.
Angling of the backrest
• To adjust the backrest, loosen the two large knobs (22) on both
sides of the seat. Adjust the angle of the backrest (23) and then
tighten the knobs again
• Adjust the backrest of the Toddler Seat so that the angle between
the backrest and the Toddler Seat is a minimum of 100 degrees
(see picture 12)
• Lean the backrest backwards only so far that the child which is
placed in the pram has sufficient room
Usage of the stroller raincover
• Place the raincover which accompanies the pram over the pram as
shown in the picture. The Toddler Seat must not be covered
• We offer no separate raincover for the Toddler Seat. We assume
that the child that is placed in the Toddler Seat is wearing weath-
erproof clothing. The Toddler Seat fabrics are made of a durable,
water repellant Protex material
• Let the Toddler Seat dry off completely after it has been used in the
rain
(the fabric is not shown in order to make the instructions clearer)
