Serial Port4 Address [2E8]
Use the Serial Port4 IRQ option to select the interrupt address for serial port 4.
Disabled
3F8
2F8
3E8
2E8
D
Parallel Port Address [378]
Use the Parallel Port Address option to select the parallel port base address.
Disabled
378
D
278
3BC
Parallel Port Mode [Normal]
Use the Parallel Port Mode option to select the mode the parallel port operates in.
Normal
Bi-directional
EPP
Page 86
No base address is assigned to serial port 4
Serial port 4 I/O port address is 3F8
Serial port 4 I/O port address is 2F8
Serial port 4 I/O port address is 3E8
Serial port 4 I/O port address is 2E8
EFAULT
No base address is assigned to the Parallel Port
Parallel Port I/O port address is 378
EFAULT
Parallel Port I/O port address is 278
Parallel Port I/O port address is 3BC
D
The normal parallel port mode is the standard mode
EFAULT
for parallel port operation.
Parallel port outputs are 8-bits long. Inputs are
accomplished by reading 4 of the 8 bits on the
status register.
The parallel port operates in the enhanced parallel
port mode (EPP). The EPP mode supports
bi-directional communication between the system
and the parallel port device and the transmission
rates between the two are much faster than the
Normal mode.
IQ7 Design Guide
