IEI Technology IQ7-US15W Bedienungsanleitung Seite 58

97 GND
99 LVDS_A0+
101 LVDS_A0-
103 LVDS_A1+
105 LVDS_A1-
107 LVDS_A2+
109 LVDS_A2-
111 LVDS_PPEN
113 LVDS_A3+
115 LVDS_A3-
117 GND
119 LVDS_A_CLK+
121 LVDS_A_CLK-
123 LVDS_BLT_CTRL
125 LVDS_DID_DAT
127 LVDS_DID_CLK
129 RSVD
131 SDVO_BCLK+
133 SDVO_BCLK-
135 GND
137 SDVO_GREEN+
139 SDVO_GREEN-
141 GND
143 SDVO_BLUE+
145 SDVO_BLUE-
147 GND
149 SDVO_RED+
151 SDVO_RED-
153 HDMI_HPD#
155 PCIE_CLK_REF+
157 PCIE_CLK_REF-
159 GND
161 PCIE3_TX+
163 PCIE3_TX-
Page 46
98 GND
100 LVDS_B0+
102 LVDS_B0-
104 LVDS_B1+
106 LVDS_B1-
108 LVDS_B2+
110 LVDS_B2-
112 LVDS_BLEN
114 LVDS_B3+
116 LVDS_B3-
118 GND
120 LVDS_B_CLK+
122 LVDS_B_CLK-
124 RSVD
126 LVDS_BLC_DAT
128 LVDS_BLC_CLK
130 RSVD
132 SDVO_INT+
134 SDVO_INT-
136 GND
138 SDVO_FLDSTALL+
140 SDVO_FLDSTALL-
142 GND
144 SDVO_TVCLKIN+
146 SDVO_TVCLKIN-
148 GND
150 SDVO_CTRL_DAT
152 SDVO_CTRL_CLK
154 DP_HPD#
156 PCIE_WAKE#
158 PCIE_RST#
160 GND
162 PCIE3_RX+
164 PCIE3_RX-
IQ7 Design Guide
