4.4.3 CompactFlash® Master/Slave Selection
Jumper Label:
Jumper Type:
Jumper Settings:
Jumper Location:
Sets the CompactFlash® slot as the IDE primary master or primary slave.
Pin Description
1-2 Slave
2-3 Master
Table 4-32: CompactFlash® Master/Slave Selection
4.4.4 CompactFlash® Voltage Selection
Jumper Label:
Jumper Type:
Jumper Settings:
Jumper Location:
Sets the voltage of the power supplied to the CompactFlash® card.
Pin Description
1-2 5.0 V
2-3 3.3 V
Table 4-33: CompactFlash® Voltage Selection
4.4.5 LAN & PCIe Enable/Disable
Jumper Label:
Jumper Type:
Jumper Settings:
Jumper Location:
JP4
3-pin header
See Table 4-32
See Figure 4–29
JP3
3-pin header
See Table 4-33
See Figure 4–29
SW3
4 switches
See Table 4-34
See Figure 4–29
Page 65
