IQ7 Design Guide
Onboard SiS USB1.1 DEVICE [Enabled]
Use the Onboard SiS USB1.1 DEVICE BIOS option to enable or disable the onboard SiS
USB1.1 controller. If disabled, USB1.1 devices cannot be used.
Disabled
Enabled
D
Onboard SiS USB2.0 DEVICE [Enabled]
Use the Onboard SiS USB2.0 DEVICE option to enable or disable the onboard SiS
USB2.0 controller. If disabled, USB2.0 devices cannot be used.
Disabled
Enabled
D
USB Configuration
The USB Configuration field shows the system USB configuration. The items listed are:
Module Version: x.xxxxx.xxxxx
USB Devices Enabled
The USB Devices Enabled field lists the USB devices that are enabled on the system
USB Functions [Enabled]
Use the USB Functions to enabled and disabled the USB ports.
Disabled
USB 8 ports
Enabled
USB 2.0 Controller [Enabled]
Use the USB 2.0 Controller BIOS option to enable or disable the USB 2.0 controller
USB 1.1 interface is disabled and cannot be used.
USB 1.1 interface is enabled and can be used.
EFAULT
USB 2.0 interface is disabled and cannot be used.
USB 2.0 interface is enabled and can be used.
EFAULT
USB ports disabled
Only the USB ports on the rear I/O panel are
activated
D
All the USB ports are enabled
EFAULT
Page 99
